Why Use the TEA- L’Europea HE 235 Scaffold Hoist
The HE 235 scaffold hoist is perfect for any building work. It will greatly speed up the logistics of getting your materials to where they are needed. What’s more just 1 person can operate the hoist and it can lift many more bricks in one go than you could in a hod. Construction workers will be much safer and the risk of injuries are greatly minimised; no more back strain from carrying heavy and awkward loads is just one problem reduced when using a scaffold hoist.
If you work on a construction site or are a builder then you will know the problems that arise when trying to haul materials up to high levels. The sheer strength needed, exertion, logistics and safety implications are immense. Imagine carrying a pile of bricks the old fashioned way in a Hod up 3 or more sets of ladders through a scaffold tower! Heavy cumbersome and slow! This is inefficient and not as safe, so get a scaffold hoist and your problems will be solved.
Key Features of the HE 235 Scaffold Hoist
- Single phase motor
- 110 or 220v
- 50Hz frequency
- 750w engine
- 23m/min average lifting speeds
- 200kg max. lifting capacity
- 35 metre cable
- 5mm cable diameter
- 40kg in weight
- 830 x 270 x 520mm dimensions
- ‘A’ frame extended reach = 745mm to 1120mm
- Pendant Control
- Scaffold Brackets included
As you can see from the features listed above there are many advantages to this hoist.
With an extendable reach frame and a 35 meter rope length the scope for lifting wide and far is great when compared to other hoists. The lifting speeds will maximise productivity, getting your materials to where they are needed fast and safe.
Other Scaffold & Gantry Hoists
We have a range of other types of scaffold hoists and builders gantry hoists (which use a separate gantry frame rather than a scaffold pole). TEA L’Europea and Imer are the key brands in this niche area and Lifting Hoists Direct can supply both.
For a different type of construction hoist/winch check out the HG 200 scaffold hoist. Rather than attaching the hoist to a scaffold pole at the top of your build, this hoist sits on the floor at any level and the rope is guided up through a scaffold mounted framework. This eliminates the need to carry the hoist up to high levels.
We can also supply a range of accessories for scaffold hoists including brick baskets, liftable wheelbarrows and more.
Contact Lifting Hoists Direct
The number to call is 01384 76961 if you would like to speak with us about any of our hoisting equipment, whether its a lever hoist, chain block or electric hoist, we are always ready to help and answer your questions. Alternatively you can email us on the contact us page.
|Motor type :||Single phase|
|Voltage : 110v/220v||110v/220v|
|Max. lifting capacity||200kg|
|Average lifting speed||23 m/Min|
|Steel cable diameter||5mm|
|Dimensions||(mm) 830 x 270 x 520|
|Extend Reach “A” Frame||745mm to 1120mm|
